Hardware

Power

DC 2.1

Ethernet

5*2.5G RJ45 Ports

1*10G SFP+ Port

Performance

Bandwidth

45Gbps

Pack forward rate

33.48Mpps

VLAN

4096

MAC address

4K

Jumbo Frame

12Kbytes

Transfer mode

Storage & forward

MTBF

100000  Hours

Standard

Network protocol

IEEE802.3 (Ethernet)

IEEE802.3u (Fast Ethernet)

IEEE802.3ab(Gigabit Ethernet)

IEEE 802.3bz (5G Ethernet)

IEEE 802.3z (Gigabit Ethernet)

IEEE 802.3ae (10G Ethernet)

IEEE802.3x (Flow control)

Industry standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)

EN61000-4-5(Surge)

Network Medium

10Base-T: Cat3, 4, 5 or above UTP/STP(≤100m)

100Base-TX: Cat5 or above UTP/STP(≤100m)

1000Base-TX: Cat5 or above UTP/STP(≤100m)

Optical Medium

multi mode: 50/125, 62.5/125, 100/140um

Single mode: 8/125, 8.7/125, 9/125, 10/125um

Certificate

Safety certificate

CE, FCC, RoHS

Environment standard

Working environment

Working Temperature: -10~50°C

Storage Temperature: -40~70°C

Working Humidity: 10%~90%, non-condensing

Storage Temperature: 5%~90%, non-condensing

Power voltage

Adapter input voltage: AC 100-240 V

switch input voltage: DC 12V1A

Indicator

PWR (Power)

On: Powered on

Off: Powered off

1-5 Port yellow light

On: 2.5G Link connect normal

Off: Link off

Flashing: data transmitting

1-5 Port green light

On: 10/100/1000M Link connect normal

Off: Link off

Flashing: data transmitting

Physical specification

Structure size

Product Size: 140*93*28mm

Package Size: 203*160*55mm

Product Net-Weight: 0.33KG

Product Gross-Weight: 0.46KG

Packing info

Carton size: 580*335*445mm

Packing Qty: 40pcs

Packing weight: 19.5KG

Packaging list

1. Switch 1pcs、

2. User manual 1pcs、

3. Certificate 1pcs、

4. Power adapter 1pcs
