10/100/1000Mbps 工业 POE 注入器

  • IP40 rated Gigabit 802.3AT/BT/PoE++ Injector
  • Max 90w POE output
  • Network a PoE device located up to 100m (328 ft.) away
  • Extreme -40 to 80 °C operating temperature range
  • DC inputs with overload current protection
  • Includes DIN-rail mount and wall mount

非常感谢您的咨询,我们会尽快处理。

PSE90W-GS   产品详情

PSE90W-GS 是一款可靠的 IP40 级工业千兆 802.3at/bt/PoE++ 注入器,其硬化组件适用于极端和恶劣的工业环境。 将 PSE90W-GS 工业 PoE 供电器连接到非 PoE 千兆交换机,然后使用最长 100 米(328 英尺)的以太网电缆将 PoE 设备联网。 PSE90W-GS 工业 PoE 供电器为 PoE、PoE+、UPoE 或 PoE++(最高 90W)设备供电。 这种工业 PoE 供电器具有带过载电流保护的直流电源输入。 DIN 导轨和壁挂式硬件均包含在工业 PoE 供电器中。

4-Pair PoE

Supplies power to a PoE (up to 15.4W), PoE+ (up to 30W), or PoE++ (up to 90W) device.

Gigabit Ports

The industrial PoE injector features 1 x gigabit port and 1 x gigabit PoE++ port.

Installation Flexibility

A rugged IP30 rated metal enclosure with DIN-rail and wall mount brackets accommodate most installations scenarios.

LED Indicators

LED indicators on the industrial PoE injector confirm PoE connectivity and Load percentage indicate.

PSE90W-GS   产品参数

Hardware Specifications
Model PSE90W-GS
Port 1*RJ45*10/100/1000M Data IN
1*RJ45*10/100/1000M PoE OUT
1* DC IN (2P) removable terminal block
Grounding point
Standard IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
DC IN DC48-57V MAX 2A
Boost efficiency
PoE Output DC37-57V 1.73A
Poe Out Watt MAX 90W
Data Pin 12345678
PoE Out 1236+ 4578-
Transmission 10Base-T: two pairs of Cat3 or latter UTP/STP(≤250m)
100Base-TX: two pairs of Cat5 or latter UTP/STP(≤150m)
1000Base-T: for pairs of Cat5e or latter UTP/STP(≤100m)
Features Plug and play without more configuration management
Under-voltage, over-voltage, Over-current and short circuit protection
Reliability:MTBF>100k hours

Lightning Protection

6KV 8/20us;6KV ESD protection

Protect grade

IP40

Environment Specifications
Operation Environment Operation Temperature:-40℃~80℃
Storage Temperature:-60℃~90℃
Operation Humidity 10%~90% RH Non coagulation
Storage Humidity 5%~90% RH Non coagulation
Product size 88mm*30mm*100mm (L*W*H)
Others
Weight 0.35kg
Warranty 3 years
