PSE4805E-AF-WT Wall mounted POE injector-POEPlus - Built Green Networks-30/60/90w industrial DC input POE injector & industrial POE splitter

PSE4805E-AF-WT

Wall mounted POE injector

Remote power feeding up to 100m
Supports PoE Power up to 15.4W for PoE port
Compatible with IEEE 802.3af Power over Ethernet
Circuit protection prevents power interference between ports
Circuit Shorting Protection Supported

PSE4805E-AF-WT Overview

As the applications of Power over Ethernet have expanded to home users from the IT industry. This Single-Port wall mounted PoE Injector meets the requirements of both the IT industry and home users for POE output and easy installation. PSE4805E-AF-WT carrying both Ethernet data and power simultaneously, It helps users to utilize just one Ethernet cable to easily install and deploy IP camera, wireless AP or VoIP phone networking in environments where power outlet is hard to find.

PSE4805E-AF-WT Specification

Items	PSE4805E-AF-WT
"Data" Input Port:	1*10/100M RJ45
"PoE (Data+Power)" Output Port	1*10/100M RJ45
Power input	100-240Vac
PoE Standards	IEEE 802.3af
Power Pin Assignment	12+ 36-
PoE Power Output	48Vdc 0.32A
Operating environment	Operating temperature: -20℃–60℃
Operating environment	Relative humidity: 5%–95% (non-condensing)
Dimensions	L100W50H34mm
Weight	TBD
Surge Protection	AC port: 3kV RJ45 port: 1.5kV
