Model
|
G08P8GE
|
|
Ports
|
8*10/100/1000bps RJ45
|
|
POE Ports
|
1port*IEEE802.3af/at/poe++/BT max 90w
7ports*IEEE802.3af/at max 30w
|
|
Power input
|
2*independent power input，40-57VDC
1*independent power input，12-57VDC（with booster to support 48V POE output）
|
|
Feature function
|
1: Max 120w POE output
2:1 group of wide voltage power input with specific boost function
3: 2 group independent power inputs with under voltage and overvoltage protection
4:DIP Switch POE watchdog enable/disable
5: DIP Switch VLAN enable/disable
|
|
Network protocol
|
IEEE 802.3
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3x
IEEE 802.3z 1000BASE-X
IEEE 802.3af/at/POE++/BT
|
|
Network port
|
1-8 port 10/100/1000BaseT（X）adaptive， Full/half duplex MDI/ MDI-X adaptive
|
|
Forward mode
|
Store-and-forward (full-line speed)
|
|
Backplane bandwidth
|
20Gbps （ Non-blocking ）
|
|
Packet forwarding rate
|
14.44Mpps
|
|
MAC table
|
2K
|
|
Packet
forwarding cache
|
2.5M
|
|
Medium
|
10BASE-T ： Cat3,4,5 UTP(≤250 meter)
100BASE-TX ： Cat5 or later UTP(≤100 meter)
1000BASE-TX ： Cat6 or later UTP(≤1000 meter)
|
|
Power consumption
|
≤5dW（none POE）；≤120W（POE full load）
|
|
LED indicator
|
POWER: Power LED
Port:(Orange=PoE LED+Green=Link LED)
|
|
Operating temperature/
humidity
|
-40～+85°C；5%～90% RH No condensation
|
|
Storage temperature/humidity
|
-55～+95°C；5%～95% RH No condensation
|
|
Product size/package size （L*W*H）
|
179×134×60mm
|
|
Net/gross weight （kg）
|
1.2kg
|
|
installation
|
Rail mounting
|
|
Lightning protection/protection level
|
Port lightning protection ：6KV 8/20us；
Protection grade ：IP40
|
|
Safety certification
|
3C；
CE mark, commercial；CE/LVD EN60950；
FCC Part 15 Class B；RoHS；
|
|
Quality assurance period
|
3 year
|
