L3 managed 4 Ports 2.5G POE Switch with 2*10G SFP+

  • 5* 10/100/1000/2500Mbps adaptive RJ45 ports,2*1G/10G SFP+ fiber uplink
  • 1 Port 802.3bt POE max 90w output
  • 3 ports 802.3af/at max 30w output
  • All ports have the wire-speed forwarding capability
  • Support MAC address self-learning;
  • Supports full-duplex working mode
  • L3 management

Thanks a lot for your inquiry and we will handle it as early as possible.

S5305GTP-2SX   Overview

S5305GTP-2SX is a 5 ports 10M/100M/1000M/2.5G auto adaptive L3 managed Switch. It provides 4 ports active POE and 1 2.5G RJ45 pure data port,and 2 ports 1G/10G SFP+ fiber uplink port. S5305GTP-2SX uses the store-and-forward mechanism and integrates high-capacity cache to ensure non-blocking line-speed forwarding on all ports. Therefore, it is suitable for high-bandwidth application.

S5305GTP-2SX   Specification

Model

S5305GTP-2SX

Product name

2.5GE L3 Poe Switch with 10G Fiber uplink

Fixed Port

5*10/100/1000/25000 Base-TX PoE portData/Power2*100/1000/250010000M SFP

PoE Ports

1 port supports IEEE802.3af/at/poe++/bt, max 90W/port PoE out

2-4 port supports IEEE802.3af/at, max 30W/port, PoE out

PoE Pin

Af/at/bt: 12+ 45+ ; 36- 78-

Af/at: 12+ 36-

PoE Bridge

max 65W

CPU

MIPS-34Kc 800GHz

Reset Key

1

FLASH

16MBytes

Bandwidth

160Gbps

Packet Forwarding

119.04Mpps

MAC

16K

Buffer

12 Mbit SRAM Packet Buffer

Jumbo Frame

Jumbo frame up to 12KB

VLAN Address

4K

Transmission Distance

10BASE-T Cat3,4,5 UTP(≤250 meter)

100BASE-TX Cat5 or later UTP(150 meter)

1000BASE-TX Cat6 or later UTP(150 meter)

2500BASE-TX Cat6 or later UTP(100 meter)

SFP: 100M/1G/10G single-mode multi-mode optical module, the maximum distance is ≤120km (depending on the optical module)

LED Indicator

PWR: Power LED

Port: Network connection indicator Green LED/100M+Orange LED/1000M

Power

External power DC52V1.25A max 65W in default

(100-240Vac 50/60Hz 0.9A)

Operating Temperature/Humidity

-10+55°C5%90% RH Non coagulation

Storage Temperature/Humidity

-40+75°C5%95% RH Non coagulation

Product /Packing size

220mm*112mm*30mm L*W*H

260mm*225mm*68mm L*W*H

N.W/G.Wkg

0.76kg/1.31kg

Lightning

Protection  level

6KV 8/20us

IP30

Installation

Desktop

Certificate

CE-EMC EN55032CE-LVD EN62368
FCC Part 15 Class B
RoHS

Warranty

Whole device for 1 year(Accessories not included)
