Model

S5348G-4SE

Fixed Port

48*10/100/1000Base-TX

4*1/2.5/5/10G SFP+

Console Port

1*console port

Reset Key

1

CPU

400MHz ARM® Cortex™-A9

DDR

4G DDR3 1333MHz

Buffer

Fully integrated 1.5 MB packet buffer

FLASH

64M

RAM

512M

Bandwidth

512Gbps

Packet Forwarding

184.64Mpps

MAC Address

16K

Network Protocol

IEEE 802.3

IEEE 802.3u 100BASE-TX

IEEE 802.3ab1000BASE-T

IEEE 802.3x

IEEE 802.3z 1000BASE-X

IEEE 802.3ad

IEEE 802.3q 、IEEE 802.3q/p

IEEE 802.1w、IEEE 802.1d 、IEEE 802.1S

STP(Spanning Tree Protocol)

RSTP/MSTP( Rapid Spanning Tree Protocol)

EPPS ring network protocol

EAPS ring network protocol

Port Specification

10/100/1000BaseT（X）Auto

Transmission Mode

Store and Forward(full wirespeed)

Transmission Distance

10BASE-T ： Cat3,4,5 UTP(≤250 meter)

100BASE-TX ： Cat5 or later UTP(≤100 meter)

1000BASE-TX ： Cat6 or later UTP(≤1000 meter)

LED Indicator

PWR:Power LED

SYS:(System LED)

1~48:(Link LED=10/100M Link、1000M=Gigabit Link）

49 50 51 52:（SFP LED）

Power

Built-in dual AC input 100~240V 50/60HZ MAX

Max Current 0.8A

Max Power 50W

Operating Temperature/Humidity

-20～+55°C；5%～90% RH Non coagulation

Storage Temperature/Humidity

-40～+75°C；5%～95% RH Non coagulation

Physical size

Product size: 440mm*290mm*45mm

Packing size: 515mm*375mm*95mm

N.W/G.W（kg）

3.5kg/4.2kg

Installation  type

1U Rack type, 19 "

Lightning protection level

3KV 8/20us；

IP30

Certificate

CE mark, commercial；CE/LVD EN60950；
FCC Part 15 Class B；RoHS；

Warranty

Whole device for 1 year(Accessories not included)
